A A   S O L A R

L I T H I U M   I R O N   P H O S P H A T E
D E E P   C Y C L E   B A T T E R I E S
**** THE BATTERY OF THE FUTURE ****
C A N   A L S O   B E   U S E D   A S   S T A R T I N G   B A T T E R I E S




Lithium Yttrium Iron Phosphate Range



Rare Earth Lithium Iron Phosphate Power Battery

The new technology replaces the previous LiFePO4 design.








GENERAL INFORMATION



At 3.3V per cell, a package of 4 cells can replace a traditional 12V lead acid battery. The bulk charging stage needs to reach 14.6V, which most modern lead acid chargers and solar controllers can be set to accommodate.

Unlike standard lead acid type batteries which have a charge efficiency of 88%, LiFePO4 batteries are over 98% efficient. Their voltage remains almost unchanged down to 80% discharged state. They can be discharged by 50% 3000 times with almost no loss of capacity within the warranty conditions.

LiFePO4 batteries are very safe. They won't leak, and don't emit explosive gasses. They are ideal for electric vehicles, mobile homes and boats. Their long life also make them superior for house use as well, and their high current capability makes them a superior performer for inverters and high impulse electric motors.


Back to Top




SPECIFICATIONS



Nominal Capacity

Available as 40Ah, 60Ah, 100Ah, 200Ah, 300Ah, and 400Ah

Operation Voltage

4 cells = 13.2V, 8 cells = 26.4V, 16 cells = 52.8V to 70% DOD

Charging Voltage

Bulk 14.6V, Equalize 15.2V (if needed), Float 13.4-13.8V (for 4 cell 13.2V battery)

Charge Current

Up to 1CA (CA = Rated Capacity)

Max Discharge Current

Constant 3CA

Impulse 20CA

Standard Charge/Discharge Current

0.5CA

Temperature Durability of Case

Less than 200°C

Operating Temperature

-45°C~85°C

Self-discharge Rate

Less than 3% monthly

Efficiency

98% - 99%




Click here for pricing




Back to Top




AA Champion Lithium Iron Phosphate

Range (LiFePO4)

Specifications for 4 cell, 13.2V Battery

Capacity
Length
Width
Height to top of Terminals
Weight
40Ah
190mm
120mm
195mm
6.2kg
60Ah
250mm
115mm
195mm
7.5kg
100Ah
145mm
258mm
235mm
13kg
200Ah
180mm
283mm
290mm
23.5kg
300Ah
220mm
363mm
328mm
39kg
400Ah
455mm
290mm
310mm
58.5kg




Image missing - refer to spec sheet




WARRANTY CONDITIONS
