For PV solar panels, including brackets and fixings. This stainless steel adjustable mounting bracket has stainless steel fasteners. Mounting brackets are easy to install, versatile and fit all sizes of AA Solar PV panels.  They allow the solar panels to be easily removed for roof maintenance.
Dimensions (Mm)
  • Option 1 35-50mm
  • Option 2 60-75mm
  • Option 3 90-105mm
$26.00
Incl. GST
  • Ships by next working day
  • Free specification service
  • In business for over 30 years
Group_52984560

Lifetime Product Support

Our Solar Engineers are available to answer any questions you may have about the products you have purchased from us
Adjustable Solar Panel Mounts
$26.00
Incl. GST

Description

Specifications

Adjustable Solar Panel Panel Mounts for PV Solar Panels includes bracket and fixings.  This stainless steel adjustable mounting bracket with stainless steel fasteners. "A" and "B Series" mounting brackets are easy to install, versatile and fit all sizes of AA Solar PV panels.  They allow the solar panels to be easily removed for roof and panel maintenance and cleaning.  Slotted screw holes allow the bracket to pivot and seat firmly on curved or slopping surfaces.  Bases may also be installed reversed to avoid other roof accessories or obstructions.

Features of Adjustable Solar Panel Mounts:

  • For RV's, vans, caravans, 5th wheelers and boats.
  • Manufactured from marine-grade stainless steel.
  • Two-piece, height and angle are adjustable.
  • Fits all standard frame solar panel
  • Allows easy panel removal for maintenance or cleaning.

A Series - for screw fixing to all roof surface types, including rubber and aluminium sheet roof.  Use 4 mounts on medium panels up to 100 watts, and 6/8 mounts on large panels up to and above 325 watts.

B Series - "No-drill" fixing for fibreglass and aluminium roofed vehicles using industrial grade 3M VHB adhesive tape.  Use mounts on medium panels, 100 to 150 watts, and 6/8 mounts on panels on larger panels 170 watts and over.

(Note: Always use the mounting holes provided by the panel manufacturer as a guide to the recommended number of mounts needed).

Features A Series B Series
Attachment SS self-tapping screws. 2 per base Very high bone adhesive tape
Adjustable height range
#1 bracket 35-50mm 35-50mm
#2 bracket 60-75mm 60-75mm
#3 bracket 90-105mm 90-105mm
Adjustable angle range O + - 5 degrees 0 + - 5 degrees
Material 2mm 3162B stainless steel 2mm 3162B stainless steel
Base attachment area dimensions 100 x 30mm 100 x 40mm


Adjustable Solar Panel Mounts Specification sheet

Please carefully read and understand all assembly instructions before commencing installation.  Installation can be quick and easing using the AA Solar Adjustable mounting brackets for flat mounting solar panels and recreational vehicles.
