IPower Series Pure Sine Wave Inverter 1500W 24V by Epever
- Ships by next working day
- Free specification service
- In business for over 30 years
Lifetime Product Support
Our Solar Engineers are available to answer any questions you may have about the products you have purchased from us
Question about this product?
We're happy to help.
Description
The IPower Series is a pure sine wave inverter designed to convert 24V DC into stable 220/230V AC power. This inverter is ideal for a wide range of off-grid and solar system applications. Its compact design, high efficiency (up to 95%), and versatile DIP switch settings make it an excellent choice for residential, commercial, or mobile setups.
Features
-
Pure Sine Wave Output – Clean, stable power for sensitive electronics
-
High Efficiency – Up to 95% energy efficiency
-
Safety Protections – Over/under voltage, overload, short circuit, and over-temperature protection
-
LED Indicators – For quick status and fault monitoring
-
Low No-Load Consumption – Ideal for solar and off-grid setups
-
Smart Cooling – Temperature-controlled fan and automatic thermal shutdown
- Two-year warranty
Specifications
Model No: IP1500-22
Continuous output power: 1200W
Output power 15 min: 1500W
Surge power: 2400W
Output voltage: 220VAC(±5%) 230VAC (-7%～+5%)
Output frequency: 50/60±0.1Hz
Output wave: Pure sine wave
Output distortion THD: THD≤3%
Load power factor: 0.2-1(Load VA ≤ Continuous output power)
Rated input voltage: 24VDC
Input voltage range: 21.6～32VDC
Input surge voltage: ＜40VDC
Max. output efficiency: 95%
No-load current: ＜0.6A
USB output: 5VDC/Max.1A
RS485 com. port: 5VDC/200mA
Dimension(LxWxH): 284.7×231.5 ×98.5mm
Mounting dimension: 163×219.5mm
Net weight: 3.9kg
Operating temperature range: -20℃~ +45℃
Relative humidity: < 95%(N.C.)
Enclosure: IP20
Datasheet
EPEVER-Datasheet-IPower (350W-2000W)
Inverters Explained
Inverters Explained
The inverter is like your solar system's brain. It manages your power flow, controlling two kinds of power. DC- or direct current - power is the kind stored in batteries. It's also the kind produced by solar panels. But you can't use DC power (Directly) to power anything in your home. That's where your inverter comes in. Everything in your home uses AC- or alternating current - power. An inverter takes DC power from your panels (or from batteries) and turns it into AC for your fridge, lights, TV, and other household appliances.
How is an off-grid inverter different from a grid-tied inverter?
A grid-tied inverter takes DC power from solar panels, turns it into AC, to use in-situ or sent to the National grid. Grid-tied inverters are more straightforward and more accessible to wire since there are usually only two main components - the inverter and your solar panels. (some grid-tied systems are starting to incorporate energy storage, but most don't have any at all. But an off-grid inverter needs a battery bank to function. Here it works: your solar panels feed DC power into the batteries. Then your inverter takes that power and "inverts" it, creating AS power for you home. This works essentially like a miniature power grid.
