• Trident Mains Battery Charger

Trident Mains Battery Charger

$261.00
$261.00 $261.00
Tax included.
Low stock! Only 10 left

Charger is an automatic mains charger for mobile and marine applications. It’s a multi-stage charger explicitly designed for Flooded, AGM and GEL battery types, but Lithium can be used with the correct settings. Featuring a compact form and can be installed or stored in small spaces. Two year warranty.

Nominal Battery Voltage
Dc Output Current
  • Ships by next working day
  • Free specification service
  • In business for over 30 years

Lifetime Product Support

Our Solar Engineers are available to answer any questions you may have about the products you have purchased from us

Question about this product?

We're happy to help.

Description

Batteries will be permanently damaged if they are overcharged or remain undercharged for any time. The TRIDENT smart battery charger will continuously deliver the right charging with built-in battery management features which will be helpful in prolonging your battery life expectancy.
Combined with up-to-date technology and TBB's knowledge of batteries, Trident smart battery charger was especially designed for mobile and marine applications. It is an ideal solution for your battery charging on board.

Features
  • Two-year warranty.
  • Active PFC featuring smaller and higher efficiency, max 92%
  • With multiple isolated outputs, including a slave charger for the starter battery
  • Automatically works as a power supply or charger
  • Sophisticated TBB premium multiple stage charging algorithm for lead acid batteries
  • Adaptive charging algorithm for multiple battery chemistries including AGM and GEL
  • LFP (LiFePO4) charging algorithm is available
  • Automatic temperature compensation charging
  • Automatic voltage compensation charging
  • Programmable with monitor
  • Special silent design
Specifications
Model No. BS1210 BS1225 BS1225-3 BS1240 BS1240-3 BS2412 BS2412-3 BS2420 BS2420-3
Electrical Specifications
Nominal output voltage (PS mode) 13.5V +/- 0.27VDC 27.0V +/- 0.5VDC
Max output current 10A 25A 40A 12A 20A
Nominal input voltage 85-265VAC, 50/60Hz 165-265VAC, 50/60Hz
Temperature compensation Automatically
Absorption voltage

AGM: 14.4V

GEL: 14.1V

LFP: 14.4V

WET: 14.7V

AGM: 28.8V

GEL: 28.2V

LFP: 28.8V

WET: 29.4V
Floating voltage

AGM: 13.5V

GEL: 13.5V

LFP: 13.5V

WET: 13.7V

AGM: 27.0V

GEL: 27.0V

LFP: 27.0V

WET: 27.4V
Charging current 10A 25A 40A 12A 20A
Efficiency 88%
Input connector Cable of 1.5m with CEE 7/7 plug ISC socket
Output connector Fixed cable, 2.5mm2, 1 M4 screw (16mm2)
Slave charger N/A max 3A
Output 1 1+1
2+1
Ripple noise  N/A ≤200mVp - p
Regulation accuracy N/A ≤ 2%
Cooling Self-cooling Fan cooling
Working temperature -20°C ~ +60°C
Protection
Short circuit Shutdown output, auto restarts when short circuit is removed
Reverse polarity No charging
Charger over temp Shutdown the charger
Battery over temp Shutdown the charger
Physical Specifications
Outer case Aluminum + plastic
Dimensions 175 x 114 x 53 mm 249 x 165 x 74 mm
Weight 1.0kg 1.6kg
IP class

IP20: For model with 1 or 2 outputs

IP22: For model with 3 outputs
Insulation resistance ≥ 50MΩ
Dielectric strength

I / P - O / P : 3.0KV

I / P - PG : 1.5KV

O / P - PG : 0.5KV
Datasheet

Trident charger BS Models Datasheet.pdf
